Спецификация
Basic Construction
|
|
24awg | 28awg | 30awg | |
| Conductor | Material | Tin Plated Annealed Cooper | Tin Plated Annealed Cooper | Tin Plated Annealed Cooper |
| Nom.Dia. | 7/0.20mm | 7/0.127mm | 7/0.10mm | |
| Foam Skin Insulation | Material | Fpe+Hdpe Skin | Fpe+Hdpe Skin | Fpe+Hdpe Skin |
| Poly Solid Insulation | Material | Hdpe | Hdpe | Hdpe |
| Shield | Material | Al+Braiding(Tin Plated Annealed Cooper) | Al Mylar+ Magnalium+Braiding | Al+Braiding(Tin Plated) |
| Coverage | ≥80% | ≥80% | ≥80% | |
| Sheath | Thickness | 0.5±0.05mm | 0.6±0.05mm | 0.6±0.05mm |
| External o.d | 10.5±0.5mm | 7.3±0.2mm | 6.0±0.2mm | |
Electrical Characteristics
| Dc Resistance 20℃(ω/Km)Max | 24awg | ＜93.25ω/Km |
| 28awg | ＜237.25ω/Km | |
| 30awg | ＜376ω/Km | |
| Insulation Impedence | Foam And Pe, Pe:Dc-500v 10 m ω.Km Min.(20℃) | |
| Na-Attenuation(Db)Max | Frequency(Mhz) | Attenuation(Db/100m)Max |
| 1-825 | 5 | |
| 826-2475 | 12 | |
| 2476-4125 | 20 | |
| 4126-5100 | 25 | |
